Steel 4130（Alloy Steel）

Material Type：Metal
Material Name：Steel 4130
Alternative Names：AISI 4130 | UNS G41300 | EN 25CrMo4 | JIS SCM430
Process Compatibility：CNC Milling, CNC Turning, Forging, Welding, Heat Treatment
Steel CNC Machining Service的副本
Steel 4130
Description
Steel 4130 is a chromium-molybdenum alloy steel known for its excellent strength-to-weight ratio, toughness, and weldability. It can be heat-treated to achieve a wide range of mechanical properties and is widely used in aerospace, automotive, and oil & gas industries.
Lead Time: < 10 days
Wall Thickness: 0.75 mm
Tolerances: ±0.005″ (±0.125mm)
Max Part Size: 200 cm x 80 cm x 100 cm

Classification of Metal Performance Parameters
Mechanical Properties Ultimate Tensile Strength 670
Yield Strength 435
Young’s Modulus / Elasticity 205
Elongation at Break 25
Hardness HB 200
Fatigue Strength 310
Physical Properties Density 7.85
Corrosion Resistance Moderate
Magnetism Magnetic
Weldability Fair
Impact Toughness High
Thermal Properties Maximum Service Temperature 470
Thermal Expansion Coefficient 11.3
Thermal Conductivity 46
Creep Resistance Moderate
Electrical Properties Electrical Resistivity 18
Electrical Conductivity 8
Dielectric Strength N/A
Processing & Surface Treatment Machinability Fair
Surface Finish Compatibility Good
Formability Fair
Special Properties Biocompatibility No
Flame Retardancy Yes
UV Resistance Low
Recyclability Yes

Introduction to Steel 4130

What
Steel 4130 (AISI 4130) contains chromium (~1%) and molybdenum (~0.2–0.3%), which provide strength, toughness, and wear resistance. It can be normalized, quenched, and tempered to achieve different property levels. Its good weldability and balance of strength and ductility make it a versatile alloy steel. It is often called “chromoly steel” in aerospace and motorsport industries.
Advantages
High strength-to-weight ratio
Excellent toughness and fatigue resistance
Good weldability and machinability for an alloy steel
Versatile heat treatment response




Applications
Aircraft engine mounts and landing gear
Roll cages and racing car frames
Oil & gas drilling tools
High-strength shafts and gears
