Stainless Steel 416

Material Type：Metal
Material Name：Stainless Steel 416
Alternative Names：UNS S41600 | EN 1.4005 | ASTM A582
Process Compatibility：CNC Turning, CNC Milling, Heat Treatment
Stainless Steel CNC Machining Service的副本
Stainless Steel 416
Description
416 Stainless Steel is a martensitic, free-machining stainless steel. By adding sulfur, its machinability is significantly improved, making it the easiest stainless steel to machine among all grades. It offers good strength and hardness after heat treatment but reduced corrosion resistance compared to 304 or 316. It is magnetic in all conditions and is widely used for precision parts requiring high machinability and moderate corrosion protection.
Lead Time: < 10 days
Wall Thickness: 0.75 mm
Tolerances: ±0.005″ (±0.125mm)
Max Part Size: 200 cm x 80 cm x 100 cm

Classification of Metal Performance Parameters
Mechanical Properties Ultimate Tensile Strength 760
Yield Strength 415
Young’s Modulus / Elasticity 200
Elongation at Break 20
Hardness HB 230
Fatigue Strength 240
Physical Properties Density 7.7
Corrosion Resistance Fair
Magnetism Magnetic
Weldability Fair
Impact Toughness Moderate
Thermal Properties Maximum Service Temperature 650
Thermal Expansion Coefficient 9.9
Thermal Conductivity 24
Creep Resistance Low
Electrical Properties Electrical Resistivity 60
Electrical Conductivity 2
Dielectric Strength N/A
Processing & Surface Treatment Machinability Excellent
Surface Finish Compatibility Good
Formability Moderate
Special Properties Biocompatibility No
Flame Retardancy Yes
UV Resistance Low
Recyclability Yes

Introduction to Stainless Steel 416

What
Stainless Steel 416 (UNS S41600) is a martensitic stainless steel developed to maximize machinability. The sulfur addition breaks up chips during machining, improving tool life and productivity on CNC lathes and mills. It can be hardened through heat treatment, reaching high strength and wear resistance. However, its corrosion resistance is lower than other stainless steels, limiting its use to less aggressive environments such as dry atmospheres, mild chemicals, or fresh water.
Advantages
Best machinability among all stainless steels
Can be hardened by heat treatment for high strength
Good dimensional stability during machining
Cost-effective for high-volume CNC production






Applications
Screws, nuts, bolts, and fasteners
Shafts and axles
Gears and valve components
Precision parts produced on CNC machines
