Stainless Steel 410

Material Type：Metal
Material Name：Stainless Steel 410
Alternative Names：UNS S41000 | EN 1.4006 | ASTM A240
Process Compatibility：CNC Milling, CNC Turning, Heat Treatment
Stainless Steel CNC Machining Service的副本
Stainless Steel 410
Description
410 Stainless Steel is a martensitic stainless steel containing 11.5–13.5% chromium. It provides good corrosion resistance along with high strength and hardness after heat treatment. While its corrosion resistance is lower than austenitic grades, it is widely used for parts requiring wear resistance, strength, and moderate corrosion protection.
Lead Time: < 10 days
Wall Thickness: 0.75 mm
Tolerances: ±0.005″ (±0.125mm)
Max Part Size: 200 cm x 80 cm x 100 cm

Classification of Metal Performance Parameters
Mechanical Properties Ultimate Tensile Strength 480
Yield Strength 275
Young’s Modulus / Elasticity 200
Elongation at Break 20
Hardness HRC 40
Fatigue Strength 200
Physical Properties Density 7.7
Corrosion Resistance Moderate
Magnetism Magnetic
Weldability Fair
Impact Toughness Moderate
Thermal Properties Maximum Service Temperature 650
Thermal Expansion Coefficient 10.4
Thermal Conductivity 24
Creep Resistance Low
Electrical Properties Electrical Resistivity 60
Electrical Conductivity 2
Dielectric Strength N/A
Processing & Surface Treatment Machinability Fair
Surface Finish Compatibility Good
Formability Moderate
Special Properties Biocompatibility No
Flame Retardancy Yes
UV Resistance Low
Recyclability Yes

Introduction to Stainless Steel 410

What
Stainless Steel 410 (UNS S41000) is the basic martensitic stainless steel. It can be hardened and tempered through heat treatment, providing high mechanical strength and wear resistance. Although it has lower corrosion resistance compared to 304 or 316, it performs well in mildly corrosive environments such as air, fresh water, and some chemicals. It is magnetic in all conditions and is often used where strength and toughness outweigh maximum corrosion protection.
Advantages
Can be heat-treated for high strength and hardness
Good wear and abrasion resistance
Moderate corrosion resistance in less aggressive environments
Cost-effective compared to higher alloy stainless steels




Applications
Cutlery and kitchen utensils
Pump and valve components
Turbine blades and parts
Fasteners and automotive components
