Aluminum 5052

Material Type：Metal
Material Name：Aluminum 5052
Alternative Names：AlMg2.5 | UNS A95052 | EN AW-5052
Process Compatibility：CNC Milling, CNC Turning
Aluminum CNC Machining Service的副本
Aluminum 5052
Description
Aluminum 5052 is a non-heat-treatable alloy with excellent corrosion resistance, especially in marine and chemical environments. It offers good formability and moderate strength, making it ideal for sheet metal parts, enclosures, and panels. It is widely used in marine components, fuel tanks, and architectural applications.
Lead Time: < 10 days
Wall Thickness: 0.75 mm
Tolerances: ±0.125mm (±0.005″)
Max Part Size: 200 x 80 x 100 cm

Classification of Metal Performance Parameters
Mechanical Properties Ultimate Tensile Strength 260
Yield Strength 193
Young’s Modulus / Elasticity 70
Elongation at Break 12
Hardness 60
Fatigue Strength 90
Physical Properties Density 2.68
Corrosion Resistance Excellent
Magnetism Non-magnetic
Weldability Good
Impact Toughness Moderate
Thermal Properties Maximum Service Temperature 200
Thermal Expansion Coefficient 23.7
Thermal Conductivity 138
Creep Resistance Moderate
Electrical Properties Electrical Resistivity 4.9
Electrical Conductivity 35
Dielectric Strength Low
Processing & Surface Treatment Machinability Good
Surface Finish Compatibility Excellent
Formability Excellent
Special Properties Biocompatibility No
Flame Retardancy Low
UV Resistance High
Recyclability Yes

Introduction to Aluminum 5052

What
Aluminum 5052 is a non-heat-treatable alloy in the 5xxx series, strengthened primarily by magnesium. It is best known for its excellent corrosion resistance, particularly in marine and chemical environments. Compared with 2xxx or 7xxx alloys, it has lower strength but much better formability and weldability.
Advantages
Excellent corrosion resistance in seawater and harsh environments
Good formability and bendability
Strong weldability without significant strength loss
High fatigue strength

Applications
Marine components and boat structures
Fuel tanks and pipelines
Pressure vessels
Architectural panels and enclosures
